商品詳細介紹
網路協定
IEEE 802.11a
IEEE 802.11b
IEEE 802.11g
WiFi 4 (802.11n)
WiFi 5 (802.11ac)
WiFi 6 (802.11ax)
IPv4
IPv6
無線速率
AX1800 ultimate AX performance : 1201 Mbps+ 574 Mbps
AX technology
Yes
傳輸速率
802.11a : up to 54 Mbps
802.11b : up to 11 Mbps
802.11g : up to 54 Mbps
WiFi 4 (802.11n) : up to 300 Mbps
WiFi 4 (802.11n) TurboQAM : up to 867 Mbps
WiFi 5 (802.11ac) : up to 867 Mbps
WiFi 6 (802.11ax) (2.4GHz) : up to 574 Mbps
WiFi 6 (802.11ax) (5GHz) : up to 1201 Mbps
天線數量
Internal dual-band antenna x 2
傳送 / 接收
MIMO 技術
2.4GHz 2x2
5GHz 2x2
記憶體
128 MB Flash, 256 MB RAM
Boosts speed
MIMO technology
無線頻段
2.4 G Hz / 5 GHz
網路連接埠
RJ45 for Gigabits BaseT for WAN/LAN x 1, RJ45 for Gigabits BaseT for LAN x1
Button
WPS Button, Reset Button
LED Indicator
Power x 1
Power Supply
"AC Input : 110V~240V(50~60Hz)
DC Output : 12 V with max. 1.5 A current"
包裝內容
XD4 Plus
‧RJ45 Ethernet cable
‧Power adapter
‧Quick start guide
‧Warranty card
‧Screw pack螺絲包
重量
307 g
AiMesh
AiMesh
Primary AiMesh router
AiMesh node
Router APP
ASUS Router APP
Alexa
Support Alexa skill
AiProtection
AiProtection Classic
Malicious site blocking
Infected Device Prevention and Blocking
家長貼心控管
Parental Control
Parental Control Customized Internet schedule
流量控管功能
Bandwidth Monitor
Bandwidth limiter
Traditional QoS
Maximum Traditional QoS rule : 32
Traffic Monitor
Real-time traffic monitor
Wired Traffic Monitor
Wireless Traffic Monitor
Wireless
IPv6
Wi-Fi Encryption : WPA3-Personal, WPA/WPA2/WPA3-Personal, WPA/WPA2-Enterprise, WPS support
UTF-8 SSID
Guest Network
Maximum Guest Network rule : 6
Guest Network Connection time limit
WPS
WAN
Internet connection Type : PPPoE, PPTP, L2TP, Automatic IP, Static IP
Android tethering
Port forwarding
Port triggering
DMZ
DDNS
Let's Encrypt
LAN
DHCP Server
IGMP snooping
IPTV
Manually assign IP address
Maximum manually assign IP address rule : 64
VPN
VPN Client L2TP
VPN Client OVPN
VPN Client PPTP
VPN Server IPSec
VPN Server OVPN
VPN Server PPTP
管理功能
Operating system : ASUSWRT
Free OS upgrade
Firewall
Wake on LAN (WOL)
SSH
Configuration backup and restore
Diagnosis tools
Feedback system
System log
使用方法說明
注意事項
【商品10日內有故障瑕疵】
可至原廠維修中心洽詢，若直接維修處理，該機型不受理退/換貨需求
若您發現購買商品有瑕疵故障，請在收受日10天內，以下述方式辦理退貨/換貨
‧請完整的將商品、配件、包裝紙盒(含內外盒)、贈品、說明書，一併放入原箱中(10日內請易註冊相關序號商品)，聯絡客服單位，我們即會派貨運來收回商品。
【鑑賞期非試用期】
‧從您收到商品開始即亨有10天鑑賞期的權益，但鑑賞期並非試用期，所您退回的商品必須是全新的狀態且包裝完整(含所有隨機贈品、主機包裝內配件、原廠內容物)
‧切勿破壞原廠外盒包裝，廠商所贈予贈品請於10天鑑賞期過後再拆封使用，否則屆時原廠將無法接受消費者退/換貨。
‧電腦軟體屬於智慧財產保護權之一，均亨有相關法律權利，若不確定是否需要，請勿拆開包裝封套，拆封視同軟體已註冊無法退貨!
‧筆記型電腦/桌機/手機/平板等主機商品貨附贈之相關軟體、活動登入禮，鑑賞期內切勿上網註冊(一經註冊恕無法接受退貨)
‧切勿塗鴉任何地方(尤其是原廠紙箱)，原廠紙箱價值1000元，保固書/使用說明書，也切勿寫字。
